Product Description:
Oiled aluminum foil has good signal shielding function and oiled lubrication function. It is widely used in CATV lead-in lines and network lines. This coating can be added to other product structures on request.
Main specifications:
Specification | Composition |
Lubricated | AL | PET |
49μm | Lubricated | 37μm | 12μm |
58μm | Lubricated | 40μm | 18μm |
64μm | Lubricated | 45μm | 19μm |
75μm | Lubricated | 50μm | 25μm |
Color:
Common color is blue and silver, can also be made red, green, gold, etc., according to customer’s needs, and can also printing and printed twill according to customer needs.
Application:
Mainly used in CATV lead-in lines and network lines, and so on.
Electrical characteristics:
mainly as an anti-electromagnetic interference is usually the case in 1-100MHZ, shielding around 70dB attenuation can be achieved with Mylar foil.
Slitting and packaging:
Slitting minimum width of 5mm, bore size of 52mm or 76mm; the winding maximum outer diameter of 800mm, carton packaging.
